H9 Flow

大型デュアルチャンバーミッドタワーATXエアフローケース

4.4
Rated 4.4 out of 5 stars
4.4 Stars (17 Reviews)
On Sale
セール価格$149.99 通常価格$169.99
$20オフ
or
Color:

Color

The NZXT H9 Flow is a white ATX case with a transparent side panel, visible front and rear cooling fans for airflow, and multiple USB ports on the bottom front edge.
H9 Flow セール価格$149.99 通常価格$169.99

Overview

H9 Flowは、高性能ビルドのために設計された広々としたミッドタワーATXケースで、エアフローと美観のバランスを取っています。デュアルチャンバーデザインは冷却とケーブル管理を改善し、穴あきパネル、角度の付いたファン、十分なファンとラジエーターのサポートにより、最適な熱性能を提供します。

  • デュアルチャンバーデザイン: 主なコンポーネントをPSUとドライブから分離し、熱性能とケーブル管理を向上。
  • 最適化されたエアフロー: 穿孔されたスチールパネルと角度のついた前右ファンが高性能ビルドのための効率的な冷却を保証。
  • 事前インストールされたファン: 前右にF140Q (CV) ファン3つ、後部にF120Q (CV) ファン1つを含む。CV = ケースバージョン (3ピンDC)
  • 10ファン容量: 上部、前右、底部に最大9つの140mmファン、後部に1つの120mmファンをサポート。
  • パノラマビュー:  シームレスでラップアラウンドの強化ガラスパネルでビルドのすべてのディテールを披露。
  • 大型ラジエーターとGPU: 上部と前右に最大420mmのラジエーターを収容し、ハイエンドグラフィックスカードのための十分なクリアランスを提供。
  • 簡単なケーブル管理: 幅広のチャンネル、内蔵のベルクロストラップ、タイダウンポイントでケーブルルーティングを簡単に。
  • バックコネクト対応: ASUS BTFやMSI Project Zeroのようなリア接続マザーボードと互換性があり、ケーブルフリーの外観を実現。
H9 Line up - Built to Flow. Made to Show.

流れるために作られた。見せるために作られた。

H9 Flowは、高性能ビルドのために設計された広々としたデュアルチャンバーケースで、広範な冷却サポートとビルドを一望できるガラスパネルを備えています。
A PC case with RGB lighting, illustrating airflow: blue arrows show cool air entering from the bottom and right, while purple arrows show warm air exiting from the top and left. Temperature display on the CPU cooler reads 32°C.

最適化されたエアフロー

前面右側のファンとエアフロー最適化レイアウトにより、温度を低く保ち、パフォーマンスを安定させます。
Close-up view of a black computer case with a mesh front panel showing two cooling fans inside. The case has a sleek, modern design with sharp edges and a partially visible glass side panel.

メッシュパネル

超微細な高気流メッシュパネルは、埃をフィルタリングしながら気流を最大化します。
Two computer towers: one black with a transparent side panel showing fans, and one white with a clear panel revealing RGB-lit components, liquid cooling, and a digital display inside.

広々としたデュアルチャンバー

発熱するコンポーネントを分離して、エアフローを改善し、クリーンなビルドを実現します。
Side view of a PC case with labeled fan/radiator mounting locations: front (3x120mm/3x140mm), top (3x120mm/3x140mm), bottom (3x120mm/3x140mm), and rear (1x120mm/1x140mm).

10ファン冷却

140mmファンを最大9基、120mmリアファンを1基取り付け可能。

A white gaming PC case with RGB fans and a digital display, showing interior liquid cooling tubes. Purple labels indicate maximum radiator sizes: 420 mm top/right, 120 mm rear, and 360 mm bottom.

ラジエーター大容量対応

上部および前面右側のパネルに最大420mmのラジエーターを取り付け可能で、多様な冷却構成に対応。
Close-up of a computers interior showing an NZXT-branded cooler with a digital display reading 32°C GPU. Purple overlay text reads Up to 435mm. Bottom right has a green label: 50 Series Ready.

マキシマムグラフィックス

435mmまでのGPUに対応し、ハイエンドグラフィックスカードに十分なスペースを提供します。
Open white computer case showing interior with highlighted motherboard tray and cable management sections in purple gradient. Multiple cable routing channels and mounting points are visible.

バックコネクト準備完了

ASUS BTFおよびMSI Project Zeroマザーボードに対応し、ケーブルのない外観を実現。

A black NZXT computer case with its side panel open, revealing an empty interior and highlighted mounting areas. A circular inset zooms in on an internal NZXT-branded strap.

簡単なケーブル管理

超広幅のチャンネル、ベルクロストラップ、固定ポイントにより、ケーブル配線が簡単になります。
Tech Specs
高さ
506 mm（19.9インチ）
幅
315 mm（12.4インチ）
奥行き
481 mm（18.9インチ）
容積
76.7 L
重量
12.46 kg（27.47ポンド）
エンクロージャタイプ
ミドルタワー
マザーボード互換性
E-ATX（最大277 mm）、ATX、Micro-ATX、Mini-ITX
背面接続式マザーボードサポート（BTF、Project Zero）
対応（ATX、Micro-ATX）
材質
SGCCスチール、透明強化ガラス（白）、着色強化ガラス（黒）
CPUクーラーの高さ
165 mm
GPUの長さ
最大459 mm（厚さ56 mm未満のファンをフロント右に取り付けた場合） 最大410 mm（厚さ56 mmの420 mm AIOとファンをフロント右に取り付けた場合）
PSUの長さ
200 mm
トップラジエーターとファンの厚さ
最大80 mm（360 mm） 最大62 mm（420 mm）
USB 3.2 Type-A
2
USB 3.2 Gen2x2 Type-C
1
ヘッドホンジャック
1
標準
7
垂直
0
2.5インチ
4+2
3.5インチ
2
フロント右
3 x 120 mm / 3 x 140 mm（3 x F140Q (CV) を含む）
トップ
3 x 120 mm / 3 x 140 mm
ボトム
3 x 120 mm / 3 x 140 mm
リア
1 x 120 mm（1 x F120Q (CV) を含む）
フロント右
最大420 mm
トップ
最大420 mm
ボトム
最大360 mm
リア
最大120 mm
モデル
F140Q (CV)
スピード
1,350 ± 150 RPM
風量
100.25 CFM
静圧
1.4 mm-H₂O
ノイズ
22.9 dBA
ファンコネクタ
3ピン
モデル
F120Q (CV)
スピード
1,350 ± 150 RPM
風量
60.2 CFM
静圧
1.05 mm-H₂O
ノイズ
24.1 dBA
ファンコネクタ
3ピン
保証
2年
型番
CM-H92FW-01 CM-H92FB-01
UPC
810074847841 810074847858
EAN
5056547207636 5056547207643
